Parker聚四氟乙烯软管PTFE

Parker PTFE hose聚四氟乙烯软管

派克的PTFE软管产品线广泛，并为大多数介质类型提供了出色的耐化学性。这些软管具有在高温和低温下运行的能力，因此可以很好地应对极端条件。每条PTFE软管摩擦力低，可*大程度地减少压降并避免积聚不必要的沉积物。它们还耐湿以避免水解。我们的PTFE软管适用于大多数主要工业市场，可支持多种应用。




耐化学腐蚀的PTFE光滑管软管-919 / 919B / 919J / 919U
PTFE软管具有出色的化学相容性，耐湿性，在宽温度范围内运行，并且摩擦系数低，有助于流动。大多数919软管可承受的温度高达450°F。




耐化学腐蚀的厚壁PTFE光滑管软管-929 / 929B
929 / 929B具有比919 / 919B软管更高的抗扭结性和更高的耐气体渗透性。929 / 929B PTFE软管具有出色的化学相容性，抗潮性，并且可在-100°F至+ 450°F的宽温度范围内使用。 螺旋四氟软管-939 / 939B
Parker卷积PTFE软管具有出色的柔韧性和抗扭结性，在化学传递，高温液压和需要紧密布线的软管应用中具有出色的性能。




PTFE软管-2030T
Parker 2030T软管专为满足液压或介质传输的高要求而设计。它们具有可靠性，多功能性和高度定制性，是生产环境的理想选择。适用于*高27.5 MPa的工作压力。




FEP高压软管-2380F
Parker 2380F软管专为满足液压或介质传输应用中的高要求而设计。它们具有可靠性，多功能性和高度定制性，是生产环境的理想选择。适用于*高42.5 MPa的工作压力。




带有硅胶外套的静电耗散平滑孔PTFE软管-929BJ
派克的929BJ软管具有静电消散PTFE芯管和棕色的可蒸汽清洁的硅胶套，可提供光滑的覆盖层，以保护不锈钢钢丝增强材料免受磨损，磨损和污染。




PTFE软管-2033T
Parker 2033T软管专为满足液压或介质传输应用中的高要求而设计。它们具有可靠性，多功能性和高度定制性，是生产环境的理想选择。适用于*高27.5 MPa的工作压力。




缠绕的PTFE软管，带316不锈钢编织层-SCW / SCB
派克SCW和SCB软管是无缝的，薄型的，对环境安全的，自排水的，并且能够承受大的挠曲。它们适用于流体处理，化学转移，油漆和半导体应用。




光滑口径不锈钢编织PTFE软管-STW / STB“真孔”
派克的STW / STB“真孔”软管与其他光滑孔PTFE软管不同，因为这些软管的内径较大，以加快介质通过管的流动。




FEP高压软管-2246F
Parker 2246F软管专为满足液压或介质传输应用中的高要求而设计。它们具有可靠性，多功能性和高度定制性，是生产环境的理想选择。适用于*高41.5 MPa的工作压力。




PTFE高压液压软管总成
派克的PTFE高压液压软管总成具有出色的化学相容性，耐潮性和承受高达5500 psi的压力。它们设计用于高温液压和化学传递应用




Flare-Seal重壁螺旋聚四氟乙烯软管
Flare-Seal组件通过提供光滑，干净的连接并防止细菌滞留来增加流量。它们可与不锈钢编织物，聚丙烯编织物或其他可选的编织物一起使用，用于流体处理和油漆应用。




带Nomex编织层的无缝回旋PTFE-NCW / NCB
带有nomex编织层的PTFE软管消除了RFI问题，并且与金属软管组件相比，它们更不容易因应力或弯曲而破裂。




带316不锈钢编织层的厚壁回旋PTFE软管-SCWV / SCBV
与SCW / SCB软管相比，SCWV / SCBV厚壁回旋PTFE软管具有更重的壁厚，可在高温下处理真空应用。




 带有EPDM橡胶套的光滑孔含氟聚合物软管-RCTW / RCTB
注意：该产品不再可用-请与我们联系以获取更多帮助。


Parker’s PTFE hose portfolio is wide-ranging and offers excellent chemical resistance for the majority of media types. These hoses have the capability to operate under both high and low temperatures and therefore handle extreme conditions very well. Each PTFE hose offers low friction, which minimises pressure drops and avoids the build-up of unwanted deposits. They are also moisture resistant to avoid hydrolysis. Our PTFE hoses are suitable for use across most major industrial markets, supporting a variety of applications.




Chemical Resistant PTFE Smoothbore Hose - 919/919B/919J/919U
PTFE hoses feature superior chemical compatibility, resist moisture, perform in a wide temperature range and offer a low coefficient of friction to assist with flow. Most 919 hoses handle temperatures up to 450°F.




Chemical Resistant Heavy Wall PTFE Smoothbore Hose - 929/929B
The 929/929B features improved kink resistance and enhanced resistance to gas permeation over 919/919B hose. 929/929B PTFE hoses feature superior chemical compatibility, resist moisture,and performs in a wide temperature range from -100°F to +450°F.




Convoluted PTFE Hose - 939/939B
Parker Convoluted PTFE Hose features excellent flexibility and kink resistance for superior performance in chemical transfer, high temperature hydraulics, and hose applications requiring tight routings.




PTFE Hose - 2030T
Parker 2030T Hoses are designed to match high demands for hydraulics or media transfer. They offer reliability, versatility and a high degree of customization and are ideal for production environments. For working pressure up to 27.5 MPa.




FEP high pressure hose - 2380F
Parker 2380F Hoses are designed to match high demands in hydraulics or media transfer applications. They offer reliability, versatility and a high degree of customization and are ideal for production environments. For working pressure up to 42.5 MPa.



Static Dissipative Smoothbore PTFE Hose with Silicone Jacket - 929BJ
Parker's 929BJ hose features a static-dissipative PTFE core tube and a brown silicone, steam cleanable jacket to provide a smooth cover to protect the stainless steel wire reinforcement against wear, fraying and contaminants.




PTFE hose - 2033T
Parker 2033T Hoses are designed to match high demands in hydraulics or media transfer applications. They offer reliability, versatility and a high degree of customization and are ideal for production environments. For working pressure up to 27.5 MPa.




Convoluted PTFE Hose with 316 Stainless Steel Braid - SCW/SCB
Parker SCW and SCB hoses are seamless, low profile, environmentally safe, self-draining and able to withstand extreme flexing. They are suitable for fluid handling, chemical transfer, paint and semiconductor applications.




Smooth Bore Stainless Steel Braided PTFE Hose - STW/STB “True-Bore”
Parker's STW/STB “True-Bore” Hose differs from other smoothbore PTFE hoses because these hoses have a larger inside diameter to speed up the flow of the media through the tube.




FEP High pressure hose - 2246F
Parker 2246F Hoses are designed to match high demands in hydraulics or media transfer applications. They offer reliability, versatility and a high degree of customization and are ideal for production environments. For working pressure up to 41.5 MPa.




PTFE High Pressure Hydraulic Hose Assemblies
Parker's PTFE High Pressure Hydraulic Hose Assemblies have exceptional chemical compatibility, resist moisture, and handle pressures as high as 5,500 psi. They are designed for use in high temperature hydraulics and chemical transfer applications




Flare-Seal Heavy Wall Convoluted PTFE Hose
Flare-Seal assemblies increase flow by providing smooth, clean connections and preventing bacterial entrapment. They are available with a stainless steel braid, polypropylene braid or other optional braids for fluid handling and paint applications.




Seamless Convoluted PTFE with Nomex Braid - NCW/NCB
PTFE hose with a nomex braid eliminates RFI issues and theyare also less susceptible to cracking from stress or flexing than metal hose assemblies.




Heavy Wall Convoluted PTFE Hose with 316 Stainless Steel Braid - SCWV/SCBV
SCWV/SCBV Heavy Wall Convoluted PTFE Hoses feature a heavier wall than SCW/SCB hoses, allowing them to handle vacuum applications at elevated temperatures.




 Smoothbore Fluoropolymer Hose with EPDM Rubber Cover - RCTW/RCTB
Note: This product is no longer available - please contact us for further assistance.



派克提供业内 广泛的特种，工业，混合和液压软管。我们全面的产品线包括耐高温，耐臭氧，耐候，耐化学腐蚀，耐油，耐火焰，耐紫外线和耐磨损的低压，中压和高压气动和液压软管。派克是全球 大的软管制造商，可为您的所有软管产品需求提供工程解决方案。
